▇  Features

Extremely low TCR

     Very low noi se and voltage coefficient

     Excellent high frequency characteristics

     Special tolerances and TCRs are available

     Epoxy thermosetting plastic package, exce llent moisture-proof function

     Alternatives to military products

▇  Detail Parameter

Resistance Range : 10m Ω - 10M Ω

Power Rating : 0.125W-1W

Tolerance : ±0.01%-1%   TCR:±5-20ppm/℃

Operating Temperature : -65 -175 ℃

▇  Applications

 Test and measurement equipments
  Instruments and meters
 Industry and Medical Drilling
 Aerospace, ships, military
